Honeywell PML Bus Interface Unit

• The BIU consists of four processes:

  • LBRCV receives tokens from local bus

  • LBTX transmits tokens on the local bus

  • BIURCV receives tokens from the global bus

  • BIUTX transmits tokens on the global bus

• The BIU is a generic module that performs handshaking for other modules

  • Shields modules from details of the bus


Copyright Honeywell, Inc. Reprinted with permission.
